GYFXTY |
|
GYFXTY, 2~12 fibers, jelly filled and fiber contained central loose tube, two parallel steel wires, PE outer sheath. Suitable for duct or aerial application. Tubes contain optical fibers colour coded as per color coding scheme. G652D SM fiber, detail..
|
|
|
|
|
|
|
|
Description
Fiber optic cable GYFXTY, 2~12 fibers, are positioned into a loose tube, tube filled with water-resistant
filling compound, then tubes (and fillers) are stranded around a central strength member (FRP), then
filled with the filling compound to protect it from water ingress. Then, the cable is completed with a PE
or AT(anti-tracking) outer sheath.
Features
¡ó Non-metal structure, good insulation, anti-thunder, can be installed with power lines & multi-thunder area;
¡ó Dedicated design satisfy different spans requirements, the largest span more than 1000mts;
¡ó Light weight and small diameter reducing the load caused by ice and wind and the load on the tower
and backstops;
¡ó Excellent performance of tensile strength and can be work in bad climate environment , long life up to
30 years;
¡ó Operating Temperature : -40~+60 ¡æ
 |
|
|
