GYXTW, 2~12 fibers, jelly filled and fiber contained central loose tube, copolymer coated steel tape, two parallel steel wires 1.2mm, PE outer sheath. Suitable for duct or aerial application. Tubes contain optical fibers colour coded as per color cod..
Product Description
 Data Sheet


Unitube fiber optic cable GYXTW, 2~12 fibers located in 1 single loose tube, jelly filled, copolymer

coated steel tape, two parallel steel wires 1.2mm, PE outer sheath. Suitable for duct or aerial application.

Tubes contain optical fibers colour coded as per color coding scheme. G652D SM fiber, available detailed

specification on your request.


¡ó Low dispersion and attenuation

¡ó Proper design, precise control for fiber excess length and distinct stranding process render the cable

    excellent mechanical and environmental properties

¡ó The armoring of corrugate steel tape ensure nice properties of moisture resistance and crush resistance

¡ó With small cable diameter, light cable weight, easily to lay

¡ó Operating Temperature : -40~+60 ¡æ
